A Series ® Lighting Controller Modbus Register Map
Summary of Registers
45
Summary of Registers
Table 89 is a summarized list of all the lighting controller registers.
System Variable
Delta Object Instance Range Property(s) Value range Func. 1/5/15 Func. 2 Func. 3/6/16 Func. 4
Device registers Device 1 Various Various 10001 – 10046
Device Setup Device 1 Various Various 50001 – 50046
Physical Inputs Multi-state Input (SW) 101 – 116 Value Enumerated 1 – 16
Physical Inputs Multi-state Input (SW) 201 – 216 Value Enumerated 17 – 32
Physical Inputs Multi-state Input (SW) 301 – 316 Value Enumerated 33 – 48
Physical Inputs Multi-state Input (SW) 401 – 416 Value Enumerated 49 – 64
Physical Inputs Multi-state Input (SW) 501 – 516 Value Enumerated 65 – 80
Multi-State Input Setup Multi-state Input (SW) 101 – 116 Setup Various 40001 – 40148
Multi-State Input Setup Multi-state Input (SW) 201 – 216 Setup Various 40101 – 40148
Multi-State Input Setup Multi-state Input (SW) 301 – 316 Setup Various 40201 – 40248
Multi-State Input Setup Multi-state Input (SW) 401 – 416 Setup Various 40301 – 40348
Multi-State Input Setup Multi-state Input (SW) 501 – 516 Setup Various 40401 – 40448
Physical Inputs Analog Input 1 – 3 Value Float 101 – 106
Physical Inputs Analog Input 601 – 608 Value Float 117 – 132
Physical Inputs Analog Input 701 – 708 Value Float 133 – 148
Physical Inputs Analog Input 1 – 3 Various Various 1001 – 1027
Physical Inputs Analog Input 601 – 608 Various Various 1101 – 1172
Physical Inputs Analog Input 701 – 708 Various Various 1201 – 1272
Physical Input Setup Analog Variable 601 – 608 Value Float 1301 – 1364
Physical Input Setup Analog Variable 701 – 708 Value Float 1401 – 1464
System Variable Delta Object Instance Range Property(s) Value range Func. 1/5/15 Func. 2 Func. 3/6/16 Func. 4
Physical Outputs Binary Output 1 to 66 Value On/Off 1 – 66
Outputs Feedback Binary Output 1 to 66 Feedback Value On/Off 1-66
Physical Outputs Binary Output 1 - 70 OutOfService On/Off 201 – 270
Special Outputs Binary Output 67 – 70 Value On/Off 67 – 70
Physical Outputs Binary Output 1 - 70 Various Various 2001 – 3260
Physical Output
Override Binary Variable 1 to 66 Override Value On/Off 3401 – 3466
System Variable Delta Object Instance Range Property(s) Value range Func. 1/5/15 Func. 2 Func. 3/6/16 Func. 4
