A Series ® Lighting Controller Modbus Register Map
Physical Output Registers-Binary Outputs (BO)
20
2559 – 2576 BO32 RW
2577 – 2594 BO33 RW
2595 – 2612 BO34 RW
2613 – 2630 BO35 RW
2631 – 2648 BO36 RW
2649 – 2666 BO37 RW
2667 – 2684 BO38 RW
2685 – 2702 BO39 RW
2703 – 2720 BO40 RW
2721 – 2738 BO41 RW
2739 – 2756 BO42 RW
2757 – 2774 BO43 RW
2775 – 2792 BO44 RW
2793 – 2810 BO45 RW
2811 – 2828 BO46 RW
2829 – 2846 BO47 RW
2847 – 2864 BO48 RW
2865 – 2882 BO49 RW
2883 – 2900 BO50 RW
2901 – 2918 BO51 RW
2919 – 2936 BO52 RW
2937 – 2954 BO53 RW
2955 – 2972 BO54 RW
2973 – 2990 BO55 RW
2991 – 3008 BO56 RW
3009 – 3026 BO57 RW
3027 – 3044 BO58 RW
3045 – 3062 BO59 RW
3063 – 3080 BO60 RW
3081 – 3098 BO61 RW
3099 – 3116 BO62 RW
3117 – 3134 BO63 RW
3135 – 3152 BO64 RW
3153 – 3170 BO65 RW
3171 – 3188 BO66 RW
Table 33. Binary Output (BO) Registers
Offset Modbus regs DB size Property Format Range Type
0 2001 Bit OutOfService Int 0–1 RW
1 2002 Byte Value Int 0–1 RW
2 2003 Bit Commissioned Int 0–1 RW
3 2004 Word Reliability Int Enum R
4 2005–2006 Dword MinimumOffTime Word 0–65536 RW
6 2007–2008 Dword MinimumOnTime Word 0–65536 RW
8 2009 Byte DefaultValue Word 0–65536 RW
9 2010–2011 Dword StartDelayTime Word 0–65536 RW
11 2012 Byte FbackValue Word 0–65536 RW
12 2013 Byte FlickWarnTime Word 0–65536 RW
13 2014 Word FlickWarnPAEnable Int On/Off RW
14 2015 Word OverrideTime Word 0–65536 RW
Table 34. Address space of binary output registers.
Binary Output (BO) Properties:
Each Binary Output (BO) object exposes the following
object properties (Table 34).
Sample Packets
Following are examples of function requests to binary
output registers.
Read All BO1 Properties
Table.35 is an example of a read of all BO1 properties:
OutOfService, Value, Commissioned, Reliability and
MinimumOffTime Reg2001–Reg2006 (Function 3, BO1in
map).
