Lighting Controller Modbus Register Map
Compact Event Log
43
Modbus reg.
DB size
Property
Format
Range
Type
0
60001- 60002
Byte
Total Events
Int
1 – 2000
R
Alarm Output Ref.
2
60003
Word
Device No
Word
0 - 65535
R
3
60004
Word
Object Type
Word
0 – 65535
BO= 4
BV= 5
R
4
60005
Word
Object Instance
Word
0 – 65535
R
5
60006
Byte
Alarm Ack
Int
0/1
R/W
6
60007- 60008
Byte
Alarm Values
Int
0 - 65535,
0 - 65535
R/W
Table 84. registers to set up alarm events and alarm output reference
*Note: Registers 60001 to 60005 must not be written to even though the can be viewed with Function 3.
Alarm Values Enabled
Reg 60007
(Hexadecimal)
Reg 60008
(Hexadecimal)
None
0000
0000
Lighting Alarms,
0000
0800
Lighting Statuses,
1000
0000
Lighting Alarms, Lighting Statuses,
1000
0800
Time Change
0002
0000
Time Change, Lighting Alarms
0002
0800
Time Change, Lighting Statuses,
1002
0000
Time Change, Lighting Alarms, Lighting Statuses
1002
0800
Device Statuses,
2000
0000
Device Statuses, Lighting Alarms,
2000
0800
Device Statuses, Lighting Statuses,
3000
0000
Device Statuses, Lighting Alarms, Lighting Statuses,
3000
0800
Device Statuses, Time Change
2002
0000
Device Statuses, Time Change, Lighting Alarms
2002
0800
Device Statuses, Time Change, Lighting Statuses,
0800
0000
Device Statuses, Time Change, Lighting Alarms, Lighting Statuses
3002
0800
Table 85. possible register values for every Lighting Alarm Value combination
Alarm Acknowledge: Register 60006 will always display
0000 hex. If the Alarm Relay is active writing 0001 hex
will acknowledge the Alarm. *When alarm is
acknowledged the value of the register will go back to
0000hex.
Alarm Values: Register 60007 – 60008 display the value of
the CEL Alarm Values bit list. Table 85 displays all
possible register values for every Lighting Alarm Value
combination possible in the Compact Event Log.
