A Series ® Lighting Controller Modbus Register Map
Physical Input Registers-Multistate Inputs (MI)
11
Multi-State Input (MI) Enumeration
Each Multi-state Input has an associated
Multi-state Input Configuration (MIC)
object that defines how the raw analog
input value is translated in an enumerated
value. The controller database defines two
of these MIC tables (Table 15 & 16)
State
# State
Name Voltage
Range
MIC1 1 Off 4-5
2 On 0-2
3 N/A 2-4
Table 15. Multi-state Input Configuration 1
State
# State
Name Voltage
Range
MIC2 1 Off 4-5
2 On 0-2
Table 16. Multi-state Input Configuration 2
The MIC associated with each Multi-state
Input is contained in the registers detailed
in table 17.
Register MI Input Type Default
40001-40003 MI-101 MIC RW MIC1
40004-40006 MI-102 MIC RW MIC1
40007-40009 MI-103 MIC RW MIC1
40010-40012 MI-104 MIC RW MIC1
40013-40015 MI-105 MIC RW MIC1
40016-40018 MI-106 MIC RW MIC1
40019-40021 MI-107 MIC RW MIC1
40022-40024 MI-108 MIC RW MIC1
40025-40027 MI-109 MIC RW MIC1
40028-40030 MI-110 MIC RW MIC1
40031-40033 MI-111 MIC RW MIC1
40034-40036 MI-112 MIC RW MIC1
40037-40039 MI-113 MIC RW MIC1
40040-40042 MI-114 MIC RW MIC1
40043-40045 MI-115 MIC RW MIC1
40046-40048 MI-116 MIC RW MIC1
40101-40103 MI-201 MIC RW MIC1
40204-40106 MI-202 MIC RW MIC1
40107-40109 MI-203 MIC RW MIC1
40110-40112 MI-204 MIC RW MIC1
40113-40115 MI-205 MIC RW MIC1
40116-40118 MI-206 MIC RW MIC1
40119-40121 MI-207 MIC RW MIC1
40122-40124 MI-208 MIC RW MIC1
40125-40127 MI-209 MIC RW MIC1
40128-40130 MI-210 MIC RW MIC1
40131-40133 MI-211 MIC RW MIC1
40134-40136 MI-212 MIC RW MIC1
40137-40139 MI-213 MIC RW MIC1
40140-40142 MI-214 MIC RW MIC1
40143-40145 MI-215 MIC RW MIC1
40146-40148 MI-216 MIC RW MIC1
40201-40203 MI-301 MIC RW MIC1
40204-40206 MI-302 MIC RW MIC1
40207-40209 MI-303 MIC RW MIC1
40210-40212 MI-304 MIC RW MIC1
40213-40215 MI-305 MIC RW MIC1
40216-40218 MI-306 MIC RW MIC1
40219-40221 MI-307 MIC RW MIC1
40222-40224 MI-308 MIC RW MIC1
40225-40227 MI-309 MIC RW MIC1
40228-40230 MI-310 MIC RW MIC1
40231-40233 MI-311 MIC RW MIC1
40234-40236 MI-312 MIC RW MIC1
40237-40239 MI-313 MIC RW MIC1
40240-40242 MI-314 MIC RW MIC1
40243-40245 MI-315 MIC RW MIC1
40246-40248 MI-316 MIC RW MIC1
40301-40303 MI-401 MIC RW MIC1
40304-40306 MI-402 MIC RW MIC1
40307-40309 MI-403 MIC RW MIC1
40310-40312 MI-404 MIC RW MIC1
40313-40315 MI-405 MIC RW MIC1
40316-40318 MI-406 MIC RW MIC1
40319-40321 MI-407 MIC RW MIC1
40322-40324 MI-408 MIC RW MIC1
40325-40327 MI-409 MIC RW MIC1
40328-40330 MI-410 MIC RW MIC1
40331-40333 MI-411 MIC RW MIC1
40334-40336 MI-412 MIC RW MIC1
40337-40339 MI-413 MIC RW MIC1
40340-40342 MI-414 MIC RW MIC1
40343-40345 MI-415 MIC RW MIC1
40346-40348 MI-416 MIC RW MIC1
40401-40403 MI-501 MIC RW MIC1
40404-40406 MI-502 MIC RW MIC1
40407-40409 Reserved - -
40410-40412 Reserved - -
40413-40415 Reserved - -
40416-40418 Reserved - -
40419-40421 Reserved - -
40422-40424 Reserved - -
40425-40427 Reserved - -
40428-40430 Reserved - -
40431-40433 Reserved - -
40434-40436 Reserved - -
40437-40439 Reserved - -
40440-40442 Reserved - -
40443-40445 Reserved - -
40446-40448 Reserved - -
Table 17. MIC associated with each Multi-state Input
