A Series
®
Lighting Controller Modbus Register Map
Schedule Objects
31
Schedule
The Controller contains 16 schedule objects that is
written by the Modbus Master. The Schedule Event
value and OutOfService property can be commanded
by Function Codes 05 and 15 and read by Function
Code 1.
Schedule Value Registers
The Schedule value registers are listed in Table 56.
Reg.
Contents
Type
Format Instance
501
SCH01 Value
RW
On/Off
01
502
SCH02 Value
RW
On/Off
02
503
SCH03 Value
RW
On/Off
03
504
SCH04 Value
RW
On/Off
04
505
SCH05 Value
RW
On/Off
05
506
SCH06 Value
RW
On/Off
06
507
SCH07 Value
RW
On/Off
07
508
SCH08 Value
RW
On/Off
08
509
SCH09 Value
RW
On/Off
09
510
SCH10 Value
RW
On/Off
10
511
SCH11 Value
RW
On/Off
11
512
SCH12 Value
RW
On/Off
12
513
SCH13 Value
RW
On/Off
13
514
SCH14 Value
RW
On/Off
14
515
SCH15 Value
RW
On/Off
15
516
SCH16 Value
RW
On/Off
16
Table 56. Schedule value registers.
Sample Packets
Table 57 is an example of a request for SCH Value
Reg501–Reg505 (Function 1, SCH1–5 in map). Note
that SCH Value Status Reg505–501 (SCH05–SCH01) is
shown as hex value 1F or binary 0001 1111, while
Reg501 is the LSB and Reg505 is the fifth bit from the
left.
Request
Response
Field Name
Hex Field Name
Hex
Device Address
01 Device Address
01
Function
01 Function
01
Register Address Hi
01 Byte Count
01
Register Address Lo
F4 SCH OutOfService 505–501
1F
Quantity of SCH Hi
00 Packet CRC Hi
Quantity of SCH Lo
05 Packet CRC Lo
Packet CRC Hi
Packet CRC Lo
Table 57. Sample packets for request for SCH Value.
Schedule OutOfService
Registers
The Schedule OutOfService registers are listed in Table
58.
Reg.
Contents
Type Format Instance
601 SCH01 OutOfService RW On/Off
01
602 SCH02 OutOfService RW On/Off
02
603 SCH03 OutOfService RW On/Off
03
604 SCH04 OutOfService RW On/Off
04
605 SCH05 OutOfService RW On/Off
05
606 SCH06 OutOfService RW On/Off
06
607 SCH07 OutOfService RW On/Off
07
608 SCH08 OutOfService RW On/Off
08
609 SCH09 OutOfService RW On/Off
09
610 SCH10 OutOfService RW On/Off
10
611 SCH11 OutOfService RW On/Off
11
612 SCH12 OutOfService RW On/Off
12
613 SCH13 OutOfService RW On/Off
13
614 SCH14 OutOfService RW On/Off
14
615 SCH15 OutOfService RW On/Off
15
616 SCH16 OutOfService RW On/Off
16
Table 58. Schedule OutOfService registers.
Sample Packets
Table 59 is an example of a request for SCH
OutOfService
status
instance
Reg601–Reg616
(Function 1, SCH1–16 in map). Note that SCH
OutOfService Status Reg4208– Reg4201 is shown as hex
value AB or binary 1010 1011, while Reg4201 is the LSB
and Reg4208 is the MSB. Reg4201 is SCH01
OutOfService Status.
Request
Response
Field Name
Hex Field Name
Hex
Device Address
01 Device Address
01
Function
01 Function
01
Register Address Hi
02 Byte Count
02
Register Address Lo 58 SCH OutOfService 608–601 AB
Quantity of SCH Hi
00 SCH OutOfService 616–609 AA
Quantity of SCH Lo
10 Packet CRC Hi
Packet CRC Hi
Packet CRC Lo
Packet CRC Lo
Table 59. Sample packets for request for SCH OutOfService status.
