A Series ® Lighting Controller Modbus Register Map
Calendar Objects
37
Request Response
Field Name Hex Field Name Hex
Device Address 01 Device Address 01
Function 03 Function 03
Register Address Hi 27 Byte Count 0E
Register Address Lo 10 Register Value Hi (10001) 00
No. of Registers Hi 10 Register Value Lo (10001) 00
No. of Registers Lo 07 Register Value Hi (10002) 00
Packet CRC Hi Register Value Lo (10002) 00
Packet CRC Lo Register Value Hi (10003) 00
Register Value Lo (10003) 03
Register Value Hi (10004) 05
Register Value Lo (10004) 0D
Register Value Hi (10005) 02
Register Value Lo (10005) 68
Register Value Hi (10006) 01
Register Value Lo (10006) 0F
Register Value Hi (10007) 03
Register Value Lo (10007) 68
Packet CRC Hi
Packet CRC Lo
Table 69. Sample packets for a read of CAL properties – OutOfService.
Read Calendar Properties Date List
Table 70 is an example of a read of CAL properties: read
the first four entries on the date list: Reg10004–Reg10011
(Function 3, CAL 1in map).
Request Response
Field Name Hex Field Name Hex
Device Address 01 Device Address 01
Function 03 Function 03
Register Address Hi 27 Byte Count 10
Register Address Lo 10 Register Value Hi (10004) 05
No. of Registers Hi
00 Register Value Lo (10004) 0D
No. of Registers Lo 08 Register Value Hi (10005) 02
Packet CRC Hi Register Value Lo (10005) 68
Packet CRC Lo Register Value Hi (10006) 01
Register Value Lo (10006) 0F
Register Value Hi (10007) 03
Register Value Lo (10007) 68
Register Value Hi (10008) 04
Register Value Lo (10085) 01
Register Value Hi (10009) 04
Register Value Lo (10009) 68
Register Value Hi (10010) FF
Register Value Lo (10010) FF
Register Value Hi (10011) FF
Register Value Lo (10011) FF
Packet CRC Hi
Packet CRC Lo
Table 70. Sample packets for a read of CAL properties – date entries.
The response is as follows:
Reg10004–Reg10005 first entry: 0x050D0268, Friday Feb
13, 2004
Reg10006–Reg10007 second entry: 0x010F0368,
Monday Mar 15, 2004
Reg10008–Reg10009 third entry: 0x04010468, Thursday
April 1, 2004
Reg10010–Reg10011 fourth entry: 0xFFFFFFFF, empty
Single Write of True to CAL OutOfService
Table 71 is an example of a single write of True to CAL1
OutOfService Reg.10001 (Function 6, CAL 1 in map).
The response is that OutOfService is True after the write.
Request Response
Field Name Hex Field Name Hex
Device Address 01 Device Address 01
Function 06 Function 06
Register Address Hi 27 Register Address Hi 27
Register Address Lo 10 Register Address Lo 10
Register Value Hi 00 Register Value Hi 00
Register Value Lo 01 Register Value Lo 01
Packet CRC Hi Packet CRC Hi
Packet CRC Lo Packet CRC Lo
Table 71. Sample packets for a single write of True to CAL1 OutOfService.
Single Write to CAL1 Date List Count
Table72 is an example of a single write of 5 to the CAL1
Date List Count Reg.10003 (Function 6, CAL1 in map).
The response is an error code, since the Date List Count is
a read-only property.
Request Response
Field Name Hex Field Name Hex
Device Address 01 Device Address 01
Function 06 Error Code 86
Register Address Hi 27 Exception Code 85
Register Address Lo 12 Packet CRC Hi
Register Value Hi 00 Packet CRC Lo
Register Value Lo 05
Packet CRC Hi
Packet CRC Lo
Table 72. Sample packets for a single write to the Date List Count Register.
Multiple Write to Edit Entry in Date List
Table 73 is an example of a multiple write to edit the
second entry of the Date List (Function 16, CAL1 in map).
This changes the second entry to August 22, 2004:
0x07160868.
