A Series ® Lighting Controller Modbus Register Map
Physical Input Registers-Analog Variable(AV)
16
Analog Variables (AV) –
Physical Input Setup
The input value behavior of the two remote
(Daylight Optimization) boards can be
altered by adjusting the parameters
represented by the Analog Variables
AV601-AV632 & AV701-AV732.
Analog Variable (AV) Object – (Registers 1301-1364 & 1401-1464)
The Analog Input Parameters (i.e. AV Present Value) are mapped as follows (Table 24):
Input
Set Point (SP)
Registers Proportional Band
Registers Reset Rate (RR)
Registers Output Value (OP)*
Register
AI-601 1301 – 1302 (AV601) 1317 – 1318 (AV609) 1333 – 1334 (AV617) 1349 – 1350 (AV625)
AI-602 1303 – 1304 (AV602) 1319 – 1320 (AV610) 1335 – 1336 (AV618) 1351 – 1352 (AV626)
AI-603 1305 – 1306 (AV603) 1321 – 1322 (AV611) 1337 – 1338 (AV619) 1353 – 1354 (AV627)
AI-604 1307 – 1308 (AV604) 1323 – 1324 (AV612) 1339 – 1340 (AV620) 1355 – 1356 (AV628)
AI-605 1309 – 1310 (AV605) 1325 – 1326 (AV613) 1341 – 1342 (AV621) 1357 – 1358 (AV629)
AI-606 1311 – 1312 (AV606) 1327 – 1328 (AV614) 1343 – 1344 (AV622) 1359 – 1360 (AV630)
AI-607 1313 – 1314 (AV607) 1329 – 1330 (AV615) 1345 – 1346 (AV623) 1361 – 1362 (AV631)
AI-608 1315 – 1316 (AV608) 1331 – 1332 (AV616) 1347 – 1348 (AV624) 1363 – 1364 (AV632)
AI-701 1401 – 1402 (AV701) 1417 – 1418 (AV709) 1433 – 1434 (AV717) 1449 – 1450 (AV725)
AI-702 1403 – 1404 (AV702) 1419 – 1420 (AV710) 1435 – 1436 (AV718) 1451 – 1452 (AV726)
AI-703 1405 – 1406 (AV703) 1421 – 1422 (AV711) 1437 – 1438 (AV719) 1453 – 1454 (AV727)
AI-704 1407 – 1408 (AV704) 1423 – 1424 (AV712) 1439 – 1440 (AV720) 1455 – 1456 (AV728)
AI-705 1409 – 1410 (AV705) 1425 – 1426 (AV713) 1441 – 1442 (AV721) 1457 – 1458 (AV729)
AI-706 1411 – 1412 (AV706) 1427 – 1428 (AV714) 1443 – 1444 (AV722) 1459 – 1460 (AV730)
AI-707 1413 – 1414 (AV707) 1429 – 1430 (AV715) 1445 – 1446 (AV723) 1461 – 1462 (AV731)
AI-708 1415 – 1416 (AV708) 1431 – 1432 (AV716) 1447 – 1448 (AV724) 1463 – 1464 (AV732)
Table 24 Analog Variable Registers
*Setting SP= -1 allows writing of the Output Value.
**Note: do NOT write to any of these registers without specific knowledge of the consequence
Analog Variable (AV) Properties
Each AV object exposes the following properties (Table25) via Function codes 3/6/16.
Offset Modbus Regs DB size Property Format Range Type
0 1301 – 1302 FLOAT Hi Value 0 – 65535 RW
2 registers per AV
Table 25. Analog Variable Properties
