GE
Preliminary Data Sheet
CAR2912TE series front-end
Input: 90Vac to 264Vac; Output: 12Vdc @ 2900W; 3.3 or 5Vdc @ 4A Standby
October 21, 2013 ©2013 General Electric Company. All rights reserved. Page 4
Feature Specifications (continued)
Parameter Symbol Min Typ Max Unit
Output Voltage programming (Vprog)
Equation: Vout = 10.8 + (Vprog * 0.96)
Vprog range V
prog
0  2.5 V
DC
Programmed output voltage range Vo 10.8  13.2 V
DC
Voltage adjustment resolution Vo  10  mV
DC
Output configured to 13.2Vdc V
prog
2.5 3.0 V
DC
Output configured to the 12Vdc set-point V
prog
3.0   V
DC
Interlock [short pin controlling presence of the 12V
DC
output]
(pulled up internally to V
stdby
by a 10kΩ resistor)
12V output ON V
I
0.7 V
stdby
 V
stdby
V
DC
12V output OFF V
I
0  0.4 V
DC
AC-OK (pulled up internally to V
stdby
by a 10kΩ resistor)
Logic High (Input within normal range) I
OH
 20 µA
V
OH
0.7 V
stdby
 V
stdby
V
DC
Logic Low (Input out of range) I
OL
  4 mA
V
OL
0  0.4 V
DC
DC-OK (pulled up internally to V
stdby
by a 10kΩ resistor)
Logic High (Output voltage is present; V
OUT
≥ 10.7Vdc) I
OH
 20 µA
V
OH
0.7 V
stdby
 V
stdby
V
DC
Logic Low (Output voltage is not present; V
OUT
≤ 10.2V
DC
) I
OL
  4 mA
V
OL
0  0.4 V
DC
Over Temperature Warning (pulled up internally to V
stdby
by a
10kΩ resistor)
Logic High (temperature within normal range) I
OH
 20 µA
V
OH
0.7 V
stdby
 V
stdby
V
DC
Logic Low (temperature is too high) I
OL
  4 mA
V
OL
0  0.4 V
DC
Delayed shutdown after Logic Low transition Tdelay 10 sec
Fault (pulled up internally to V
stdby
by a 10kΩ resistor)
Logic High (No fault is present) I
OH
 20 µA
V
OH
0.7 V
stdby
 V
stdby
V
DC
Logic Low (Fault is present) I
OL
  4 mA
V
OL
0  0.4 V
DC
PS Present [internally connected to Output return]
(Needs to be pulled HI via an external resistor)
Logic High (Power supply is not plugged in)
Logic Low (Power supply is present) V
IL
0  0.1 V
DC
8V_INT (no components should be connected to this pin)
