GE
Preliminary Data Sheet
CAR2912TE series front-end
Input: 90Vac to 264Vac; Output: 12Vdc @ 2900W; 3.3 or 5Vdc @ 4A Standby
October 21, 2013
©2013 General Electric Company. All rights reserved.
Page 15
STATUS_VOUT (0X7A):
Returns one byte of information of
output voltage related faults.
Bit
Position
Flag
Default
Value
7
VOUT OV Fault
0
6
VOUT_OV_WARNING
0
5
VOUT_UV_WARNING
0
4
VOUT UV Fault
0
3 - 0
X
0
STATUS_IOUT (0X7B):
Returns one byte of information of
output current related faults.
Bit
Position
Flag
Default
Value
7
IOUT OC Fault
0
6
X
0
5
IOUT OC Warning
0
4
X
0
3
CURRENT SHARE FAULT
0
2
IN POWER LIMITING MODE
0
1 - 0
X
0
STATUS_INPUT (0X7C):
Returns one byte of information of
input voltage related faults.
Bit
Position
Flag
Default
Value
7
VIN_OV_Fault
0
6
VIN_OV_Warning
0
5
VIN_UV_ Warning
0
4
VIN_UV_Fault
0
3
Unit OFF for low input voltage
0
2
IIN_OC_Fault
0
1 - 0
X
0
STATUS_TEMPERATURE (0x7D):
Returns one byte of
information of temperature related faults.
Bit
Position
Flag
Default
Value
7
OT Fault
0
6
OT Warning
0
5 - 0
X
0
STATUS_CML (0X7E):
Returns one byte of information of
communication related faults.
Bit
Position
Flag
Default
Value
7
Invalid/Unsupported Command
0
6
Invalid/Unsupported Data
0
5
Packet Error Check Failed
0
4 - 2
X
0
1
Other Communication Fault
0
0
X
0
Read back Descriptions
Single parameter read back:
Functions can be read back one
at a time using the read_word_protocol with PEC. A
command is first sent out notifying the slave what function is
to be read back followed by the data transfer.
Analog data is always transmitted LSB followed by MSB. A NA
following the PEC byte signifies that the transmission is
complete and is being terminated by the ‘host’.
1
8
1
8
1
S Slave address
Wr A Command Code
A
1
8
1
Sr Slave address
Rd
A
8
1
8
1
8
1
1
LSB
A
MSB
A
PEC NA
P
Read_fan_speed 1 & 2 (0x90, 0x91):
Reading the fan speed is
in Direct Mode returning the RPM value of the fan.
Read_FRU_ID (0x99,0x9A,0x9B,0x9E):
Returns FRU
information. Must be executed one register at a time.
1
8
1
8
1
S
Slave address
Wr A
Command 0x9x
A
1
8
1
8
1
Sr
Slave address
Rd
A
Byte count = x
A
8
1
8
1
8
1
8
1
1
Byte_1
A Byte A
Byte_x
A PEC NA P
Mfr_ID (0x99):
Manufacturer in ASCII – 5 characters
maximum,
General Electric – Critical Power represented as,
GE-CP
Mfr_ID (0x9A):
Manufacturer model-number in ASCII – 16
characters, for this unit: CAR2912TEBXXZ01A
Mfr-revision (0x9B):
Total 4 bytes
Each byte is partitioned into high and low nibbles
Example: FF is read as 16.16
00 is read as 1.1
Series
Hardware Rev
Primary µC
Secondary µC
Mfr_serial (0x9E):
Product serial number includes the
manufacturing date, manufacturing location in up to 15
characters. For example:
13KZ51018193xxx, is decoded as;
13 – year of manufacture, 2013
KZ – manufacturing location, in this case Matamoros
51 – week of manufacture
018193xxx – serial #, mfr choice
