GE Industrial Solutions AF-650 GP General Purpose Drive (460_575_690V 125HP and above) User Manual
Page 48
Illustration 3.43: Position of earth terminals IP00 (Chassis), Unit Size 44
Illustration 3.44: Position of earth terminals IP21 (NEMA type 1) and IP54
(NEMA type 12)Unit Size 42
NB!
Unit Size 42 and 44 are shown in above examples. Unit Size 41 and 43 are equivalent.
AF-650 GP High Power Operating Instructions
47
3
