Mains Supply 3 x 525- 690 VAC
AF-650 GP
50 HP
60 HP
75 HP
100 HP
125 HP
Heavy Duty/Light Duty*
HD
LD
HD
LD
HD
LD
HD
LD
HD
LD
Typical Shaft output at
550 V [kW]
30
37
37
45
45
55
55
75
75
90
Typical Shaft output at
575 V [HP]
40
50
50
60
60
75
75
100
100
125
Typical Shaft output at
690 V [kW]
37
45
45
55
55
75
75
90
90
110
IP21/Nema 1 Drive Type
41
41
41
41
41
IP54/Nema 12 Drive
Type
41
41
41
41
41
IP00 Open Chassis Drive
Type
42
42
42
42
42
Output current
Continuous
(at 550 V) [A]
48
56
56
76
76
90
90
113
113
137
Intermittent (60 sec
overload)
(at 550 V) [A]
77
62
90
84
122
99
135
124
170
151
Continuous
(at 575/ 690 V) [A]
46
54
54
73
73
86
86
108
108
131
Intermittent (60 sec
overload)
(at 575/ 690 V) [A]
74
59
86
80
117
95
129
119
162
144
Continuous KVA
(at 550 V) [KVA]
46
53
53
72
72
86
86
108
108
131
Continuous KVA
(at 575 V) [KVA]
46
54
54
73
73
86
86
108
108
130
Continuous KVA
(at 690 V) [KVA]
55
65
65
87
87
103
103
129
129
157
Max. input current
Continuous
(at 550 V ) [A]
53
60
60
77
77
89
89
110
110
130
Continuous
(at 575 V ) [A]
51
58
58
74
74
85
85
106
106
124
Continuous
(at 690 V ) [A]
50
58
58
77
77
87
87
109
109
128
Max. cable size, mains,
motor, load share and
brake [mm
2
(AWG)]
2x70 (2x2/0)
Max. external pre-fuses
[A]
1
125
160
200
200
250
Estimated power loss
at rated max. load [W]
4)
1355
1458
1459
1717
1721
1913
1913
2262
2264
2662
Weight,
Unit Size IP21, IP 54 [kg]
96
Weight,
Unit Size IP00 [kg]
82
Efficiency
4)
0.97
0.97
0.98
0.98
0.98
Output frequency
0 - 600 Hz
Heatsink overtemp. trip
85 °C
Power card ambient trip
60 °C
* Heavy Duty = 160% torque during 60 s, Light Duty = 110% torque during 60 s
