Appendix C

– 88 –

PCI-1710 series User’s Manual

Advantech Co., Ltd.
www.advantech.com

C.13 D/A Output Channel 1 - BASE+12 and BASE+13

The write-only registers of BASE+12 and BASE+13 accept data for D/
A channel 1 output.

PCI-1710L/1710HGL/1711L/1716L

The PCI-1710L/1710HGL/1711L/1716L is not equipped with the D/A
functions.

PCI-1711/1710HG/1711/1716

Table C-15: Register for D/A channel 1 data

Write

D/A Output Channel 1

Bit #

7

6

5

4

3

2

1

0

BASE + 13 *DA15

*DA14

*DA13

*DA12

DA11

DA10

DA9

DA8

BASE + 12

DA7

DA6

DA5

DA4

DA3

DA2

DA1

DA0

*: DA15, DA14, DA13, DA12 are only supported for PCI-1716/1716L

DA11 ~ DA0

Digital to analog data

DA0

LSB of the D/A data

DA11

MSB of the D/A data (for PCI-1710/1710L/1710HG/
1710HGL/1711/1711L)

DA15

MSB of the D/A data (for PCI-1716/1716L)
