Appendix A
– 58 – PCI-1710 series User’s Manual Advantech Co., Ltd.
www.advantech.com
PCI-1711/1711L
Analog Input:
Channels 16 Single-Ended
Resolution 12-bit
FIFO Size 1K samples
Max. Sampling Rate 100 KS/s max.
Conversion Time 10 µs
Input range and
Gain List
Gain 1 2 4 8 16
Input ± 10 V ± 5 V ± 2.5 V ± 1.25 V ± 0.625 V
Drift
(ppm/°C)
1 2 4 8 16
Zero 15 15 15 15 15
Gain 25 25 25 30 40
Small Signal
Bandwidth for PGA
1 2 4 8 16
Bandwidth 4.0 MHz 2.0 MHz 1.5 MHz 0.65 MHz 0.35 MHz
Max. Input
Overvoltage
±15 V
Input Protect 70 Vp-p
Input Impedance 2 M Ω /5 pF
Trigger Mode Software, On-board Programmable Pacer or externa
Accuracy
DC
INLE: ±0.5 LSB
Monotonicity: 12 bits
Offset error: Adjustable to zero
Gain error: 0.005% FSR (Gain=1)
AC
SNR: 68 dB
ENOB: 11 bits
