9. Appendices VlinxMESR9xx Modbus Gateway
Page 67 Manual Documentation Number MESR9xx-2113m
www.bb-elec.com/
www.bb-europe.com/
General Specifications
Hardware and
included accessories
Device
MESR901-x, MESR902D-x or
MESR902T-x Modbus gateway module
CD
CD with Vlinx Modubs Manager software
for Windows 2000, XP (32/64 bit), 2003
Server (32/64 bit), Vista (32/64 bit), 2008
Server (32/64 bit), Windows 7 (32/64 bit)
Optional Accessories Cable
232NM9 Null Modem Crossover Cable for
DTE to DTE connection
Rail
ERS35 one-meter length of steel 35mm
DIN Rail
Configuration Options Via serial port
Using Vlinx Modbus Manager via a serial
connection, (press Reset button to enter
Console Mode)
Via network
Using Vlinx Modbus Manager via a
Ethernet connection
Using a standard web browser such as
Internet Explorer 6.0/7.0 or Firefox 1.5/2.0
Software
Vlinx Modbus
Manager for Modbus
gateway configuration
Windows 2000, XP (32/64 bit), 2003
Server (32/64 bit), Vista (32/64 bit), 2008
Server (32/64 bit), Windows 7 (32/64 bit)
Environment
Operating
Temperature
-40 to 80 °C (-40 to 176 °F)
Storage Temperature -40 to 85 °C (-40 to 185 °F)
Operating Humidity 10 to 95% non-condensing
Certifications FCC Part 15 Class A
CE
UL UL Listed, File E222870
UL Class1 Div2
Groups A, B, C, D (HAZLOC) File
E245458
TS2
Enclosure Rating IP30
Mounting DIN rail mount (35 mm)
Dimensions, Medium
Case (MESR92x)
1.2 x 4.5 x 6.2 in (2.8 x 11.4 x 15.7 cm)
Dimensions, Small
Case (MESR90x)
1.2 in x 3.3 x 4.7 in (3.1 x 8.4 x 11.9 cm)
Power Supply
(External Supply
Required)
Voltage Requirements 10 to 48 VDC (58 VDC Max)
Power Consumption
MESR90x – 4.0W (Max)
MESR92x – 6.0W (Max)
