2. Hardware

VlinxMESR9xx Modbus Gateway

Page 10

Manual Documentation Number MESR9xx-2113m

www.bb-elec.com/

www.bb-europe.com/

Power Connector

The power connector is a 2-position pluggable terminal block.

Figure 10. Power Connection

Mounting Hardware

MESR9xx Modbus Gateway modules can be DIN rail mounted. The DIN mounting clip
and spring is included on each module.

Figure 11. DIN Clips on Modbus Gateway Modules. Large DIN clips are used on MESR92x, small DIN clips on MESR90x.
