3. Setup and Connections VlinxMESR9xx Modbus Gateway
Page 36 Manual Documentation Number MESR9xx-2113m
www.bb-elec.com/
www.bb-europe.com/
2. Method 2: Change the Modbus Gateway’s network settings to match your PC using
Console Mode
a. Connect a null modem serial cable (crossover cable) from port 1 on the
Modbus Gateway to an available COM port on your PC.
b. Open Hyper Terminal or similar serial emulation software and connect to the
COM port used in step one. Ensure the port is configured to 115,200 baud, 8
data bits, no parity, and 1 stop bit.
c. Enter Console Mode. Press and hold the Modbus Gateway’s for 2 to 10
seconds. The LED indicators will respond as follows:
Model Port 1 LED Port 2 LED Ready LED
MESR9x1 OFF XXXXXXX ON
MESR9x2 OFF ON OFF
d. Release the reset button. The READY LED will blink once per second for five
seconds. This indicates that the Modbus Gateway is re-booting in Console
Mode.
e. When the Modbus Gateway has successfully restarted in Console Mode, the
READY LED will be OFF and the PORT 1 LED will be ON.
f. Open the Vlinx™ Modbus Manager Software and select “Serial Port” as the
method to connect to the Modbus Gateway.
g. After logging in, click on .
h. Un-check the box next to “I Want DHCP to setup the Network.”
i. Re-configure the Modbus Gateway’s network settings to something within the
range of your PC’s network settings. For example:
PC Network Settings
IP Address = 192.168.0.1
Subnet Mask = 255.255.0.0
Default Gateway = 192.168.0.100
Change the Modbus Gateway’s network settings to:
IP Address = 192.168.0.50
Subnet Mask = 255.255.0.0
Default Gateway = 192.168.0.100
