3. Setup and Connections VlinxMESR9xx Modbus Gateway
Page 33 Manual Documentation Number MESR9xx-2113m
www.bb-elec.com/
www.bb-europe.com/
Note: For more information on configuration options refer to Section 4: Description of Modbus
gateway Properties.
Configuring with the Web Interface
MESR9xx Modbus Gateways can be configured over the network using a standard
internet browser such as Internet Explorer or Firefox.
To open the web configuration interface:
1. On a PC connected to the network, open a web browser.
Figure 41. Open Web Browser
2. In the browser’s address bar, type the IP address of the Modbus gateway.
Figure 42. Type IP Address
