Introduction Vlinx MESP211 Modbus Gateway
6
MESP211 FEATURES
 DB9M and pluggable terminal block serial port connector options
 Software selectable as RS-232, RS-422 or RS-485 2- or 4-wire
 Configuration of Ethernet and serial port settings using software
 Configuration can be done via network, web page or direct serial connection
 Slim line panel mountable case with DIN rail mount option
 Accepts 10 – 30 VDC power
 10/100 Mbps Ethernet with Auto Selection, Auto MDI/MDIX
 LAN and WAN Communications
 Modbus TCP Client or Modbus TCP Server - configurable
 Firmware Upload for future revisions/upgrades
 Software Support - Windows XP (32/64 bit), 2003 Server (32/64 bit), Vista
(32/64 bit), 2008 Server (32/64 bit), Windows 7 (32/64 bit), Windows 8
(32/64 bit), Windows Server 2012
CONFIGURATION SOFTWARE
The configuration software enables you to find connected Modbus Gateways, configure
them, upgrade Modbus Gateway firmware, and save/load configuration files. It features a
graphical user interface (GUI) that is convenient and easy to use.
