Setup and Connections

Vlinx MESP211 Modbus Gateway

18

CONFIGURING THE MESP211 VIA THE NETWORK CONNECTION

When configuring via the network, either Modbus Gateway Manager software or the web
interface can be used.

CONFIGURING THE MODBUS GATEWAY MANAGER

MESP211 Modbus Gateways can be configured over the network Modbus Gateway Manager
software running on a PC.

To open Modbus Gateway Manager:

1. From the Desktop, click Start  Programs  B&B Electronics  Vlinx  Vlinx

Modbus Gateway ManagerModbus Gateway Manager. An alternate method is to
double click the shortcut installed on the desktop.

Opening Vlinx Modbus Gateway Manager

Figure 19.
