Setup and Connections Vlinx MESP211 Modbus Gateway
35
b. The first box in line is the starting ID of a range you want to route. Valid
value range is from 1 to 247.
c. The second box in line is the last ID of that range. Valid value range is from 1
to 247.
d. The third box in line is a port or IP address which has slave devices attached.
e. The fourth box in line is an IP address of the slave device if IP address is
chosen in the third box.
f. Save settings by clicking the “Save” button.
10. Modbus Priority
a. To access this screen, click the “Next” button or click the “Modbus Priority”
link on the left side of the screen.
b.
This screen allows you to configure the gateway to move high priority
messages to the front of the serial message buffer
.
Modbus Priority Screen
Figure 36.
c. These settings allow the gateway to move high priority messages to the front
of the serial message buffer. The priority can be based on the originating
