Product Introduction
Manual Documentation Number: ZXTx-IO-x-4113m
5
2
2
.
.
P
P
r
r
o
o
d
d
u
u
c
c
t
t
I
I
n
n
t
t
r
r
o
o
d
d
u
u
c
c
t
t
i
i
o
o
n
n
2.1
Zlinx Xtreme I/O
Product Models
Zlinx Xtreme I/O modules provide easy-to-use, cost-effective Peer-to-Peer (wire replacement) or Modbus connectivity
solutions through license free wireless spectrum.
Figure 2-1 Zlinx Xtreme I/O Modules
.
Following I/O models are available:
1) ZXT24-IO-222R2
2.4 GHz, Short range, IP67 I/O module (2 Analog In, 2 Analog Out, 2 Digital In, 2 Relay Out)
2) ZXT9-IO-222R2
900 MHz, Long range, IP67 I/O module (2 Analog In, 2 Analog Out, 2 Digital In, 2 Relay Out)
2.2
Package Contents
Zlinx Xtreme IO Modules are shipped with the following items included:
Zlinx Xtreme I/O module.
Standard antenna.
Optional mounting ears
Mounting screws
o
M4-0.7 25mm SS Phillips Pan Hd Machine Screws
– qty. 4
o
M4-0.7 x 25mm SS Hex Head Cap screws
– qty. 4
o
M4-0.7 DIN 985 A4 S/S Nylon Insert Lock Nuts
– qty. 4
A printed version of the Modbus Mode Zlinx I/O Quick Start Guide.
A printed version of the Peer-to-Peer Mode Zlinx I/O Quick Start Guide.
