73
8048B–AVR–03/09
Table 11-7. Overriding Signals for Alternate Functions in PA1..PA0
Table 11-6. Overriding Signals for Alternate Functions in PA3..PA2
Signal
Name
PA3/ADC3/PCINT3 PA2/ADC2/PCINT2
PUOE 0
PUOV 0 0
DDOE 0
DDOV 0 0
PVOE 0
PVOV 0 0
PTOE 0 0
DIEOE (PCINT3 • PCIE0) + ADC3D (PCINT2 • PCIE) + ADC2D
DIEOV PCINT3 • PCIE0 PCINT2 • PCIE0
DI PCINT3 Input PCINT2 Input
AIO ADC3 Input ADC2
Signal
Name
PA1/ADC1/PCINT1 PA0/ADC0/PCINT0
PUOE 0
PUOV 0 0
DDOE 0
DDOV 0 0
PVOE 0
PVOV 0 0
PTOE 0 0
DIEOE (PCINT1 • PCIE) + ADC1D (PCINT0 • PCIE0) + ADC0D
DIEOV PCINT1 • PCIE0 PCINT0 • PCIE0
DI PCINT1 Input PCINT0 Input
AIO ADC1 Input ADC0 Input
