155
8048B–AVR–03/09
20. Electrical Characteristics
20.1 Absolute Maximum Ratings*
20.2 DC Characteristics
Note: All DC Characteristics contained in this data sheet are based on simulation and characterization of other AVR microcontrollers
manufactured in the same process technology. These values are preliminary values representing design targets, and will be
updated after characterization of actual silicon.
Operating Temperature.................................. -55
°
C to +125
°
C
*NOTICE: Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.
Storage Temperature ..................................... -65°C to +150°C
Voltage on any Pin except RESET
with respect to Ground ................................-0.5V to V
CC
+0.5V
Voltage on RESET with respect to Ground......-0.5V to +13.0V
Maximum Operating Voltage ............................................ 6.0V
DC Current per I/O Pin ............................................... 40.0 mA
DC Current V
CC
and GND Pins................................ 200.0 mA
Table 20-1. DC Characteristics. T
A
= -40
°
C to 85
°
C
Symbol Parameter Condition Min. Typ. Max. Units
V
IL
Input Low Voltage,
Any Pin as I/O
V
CC
= 1.8V - 2.4V -0.5 0.2V
CC
(1)
V
V
CC
= 2.4V - 5.5V -0.5 0.3V
CC
(1)
V
Input Low Voltage,
RESET Pin as Reset
(2)
V
CC
= 1.8V - 5.5V -0.5 0.2V
CC
(1) V
V
IH
Input High-voltage,
Any Pin as I/O
V
CC
= 1.8V - 2.4V 0.7V
CC
(3)
V
CC
+0.5 V
V
CC
= 2.4V - 5.5V 0.6V
CC
(3)
V
CC
+0.5 V
Input High-voltage,
RESET Pin as Reset
(2)
V
CC
= 1.8V to 5.5V 0.9 V
CC
(3)
V
CC
+0.5 V
V
OL
Output Low Voltage
(4)
,
Pins PB1, PB2, PB4 and PB5
(5)
I
OL
= 20 mA, V
CC
= 5V 0.8 V
I
OL
= 10 mA, V
CC
= 3V 0.8 V
I
OL
= 4 mA, V
CC
= 1.8V 0.8 V
Output Low Voltage
(4) ,
All Other I/O Pins, except RESET
pin
I
OL
= 10 mA, V
CC
= 5V 0.8 V
I
OL
= 5 mA, V
CC
= 3V 0.8 V
I
OL
= 2 mA, V
CC
= 1.8V 0.8 V
V
OH
Output High-voltage
(6)
All I/O Pins, except RESET pin
I
OH
= 10 mA, V
CC
= 5V 4.0 V
I
OH
= 5 mA, V
CC
= 3V 2.3 V
I
OH
= 2 mA, V
CC
= 1.8V 1.4 V
I
LIL
Input Leakage Current, I/O Pin V
CC
= 5.5 V, pin low -1 1 µA
I
LIH
Input Leakage Current, I/O Pin V
CC
= 5.5 V, pin high -1 1 µA
