Ohaus DEFENDER 7000 BENCH SCALES Manual en User Manual
Page 8
EN-6 7000 Series Indicators
1.2
Overview of Parts and Controls
1
16 15 14 13 12 11
2
3
4
5
6
7
8
9
10
Item
Description
1
Data label (on side)
2
Front housing
3
Control Panel
4
Adjusting knob (2)
5
Mounting bracket
6
Security screw
7
Rear housing
8
Data label
9
Battery cover
10
Screw (4)
11
RS232 connector
12
Cable gland for Scale 2
load cell cable or option
cable
13
Load cell connector for
Scale 1
14
Cable gland for Scale 1
load cell cable
15
Hole plug for option
16
Power receptacle
Figure 1-1. T71P Indicator
