7000 Series Indicators EN-41
T-S-S
S-S
FUNCTION
PRINT
ZERO
I-O
INPUT
TARE
INPUt
OFF
I-O
INPUT BEEP
ON
IN.bEEP
OFF
I-O
OUTPUT
OUtPUt
TYPE
CLOSED
tYPE
OPEN
OUtPUt
SEQUENCE
HOLD
SE9
NORMAL
3.11.2 External Input
Set the function to be controlled by an optional external input device, such as a footswitch.
OFF = disabled
TARE = equivalent to pressing the TARE button.
ZERO = equivalent to pressing the ZERO button.
PRINT = equivalent to pressing the PRINT button.
FUNCTION = equivalent to pressing the FUNCTION button.
S-S = when the optional relay pc board is installed, the first external input
changes the state of the relay; the second external input returns the
relay to the original state (START-STOP).
T-S-S = when the optional relay pc board is installed, the first external input
changes the state of the relay; the second external input returns the
relay to the original state (TARE-START-STOP).
3.11.3 Input Beep
Set the beeper response to an external input.
OFF = the beeper does not sound.
ON = the beeper sounds.
3.11.4 Relay Output Sub-menu
Set the relay output parameters.
NOTE: The Relay Output sub-menu and associated menu items are not displayed unless the
optional Relay PC Board is installed.
Type
Set the initial state of the relay.
OPEN = the relay output is normally open.
CLOSED = the relay output is normally closed.
CAUTION: The normally closed relay condition is only active while the indicator is powered on.
When powered off or when power is removed, the relay condition returns to a normally open condition.
Restoring power to the indicator will restore the closed condition of the relays.
Output Sequence
Set how the relay outputs react as the weight reading changes from under to accept, accept to over.
NORMAL = the previously enabled relay will be disabled as the next relay is
enabled.
HOLD = the previously enabled relay will hold the same state as the next relay
is enabled.
