EN-48 7000 Series Indicators
*
0
0.000
kg
ENTER APW
*
0
0.000
kg
1 s
*
0
0.000
kg
s2
mMOdE
WEIGHING
mMOdE
COUNTING
*
0
0.000
kg
COUNt
Pcs
CLEAR APW?
*
0
0.000
kg
PLACE 10 OR
*
0
0.000
kg
PLACE 20 OR
*
0
1.123
kg
*
0
1.1234
kg
4.7 Printing Data
Press the PRINT button to send data to a printer or computer.
NOTE: To ensure that the desired data is output correctly, first set the printing parameters (Section 3.9)
and the Communication parameters (Section 3.10).
NOTE: Data may also be printed using the P command. (See Section 5.1.)
4.8 Dual Scale Operation
If a second scale base is attached to the indicator, press and hold the 1s2 button to alternate the
display between the readings for scale 1 and scale 2. The scale symbol on the display identifies
which scale is active. 1s indicates that scale 1 is active.s2 indicates that scale 2 is active.
NOTE: DUAL SCALE must be set to ON in the SETUP menu and the second scale must be set up and
calibrated.
4.9 Application Modes
Press and hold Mode until the desired application mode is displayed, then release the button.
NOTE: Only modes enabled in the Mode menu will be displayed. (See Section 3.6.)
4.9.1
Weighing
Use this mode to weigh items in the desired unit of measure.
Place the item to be weighed on the scale and read the value on the display.
NOTES: Press FUNCTION to display the weight briefly in 10x expanded resolution if Accumulate is
set to OFF in the Setup menu.
Press FUNCTION to add the displayed count to the accumulation data if Accumulate is set
to MANUAL in the Setup menu.
If Accumulate is set to AUTO in the Setup menu, the displayed weight is automatically
added to the accumulation data when the reading becomes stable.
4.9.2
Parts Counting
Use this mode to count parts of uniform weight. The indicator supports positive counting and
negative counting. Positive counting refers to counting parts as they are added to the empty scale.
Negative counting refers to counting parts that have already been added to the scale.
NOTES: If Accumulate is set to OFF in the Setup menu, the second line displays the weight in
current unit by default. Pressing FUNC can switch the second line display between weight
and APW.
If Accumulate is set to MANUAL in the Setup menu, press FUNCTION to add the displayed
count to the accumulation data.
If Accumulate is set to AUTO in the Setup menu, the displayed count is automatically added
to the accumulation data when the reading becomes stable.
Defining the Average Piece Weight for Positive Counting
To define the average piece weight (APW), place a specified quantity on the scale.
When the Mode button is released, CLEAR APW? appears.
Press No to use the stored APW or press Yes to establish a new APW.
When establishing a new APW, the display alternates between PLACE 10 OR and ENTER APW.
NOTE: To change the specified number of pieces, press No repeatedly. The display will step through
the alternative sample sizes: PLACE 5, PLACE 10, PLACE 20, PLACE 50 and PLACE 100.
