EN-54 7000 Series Indicators
NAmME
W001
NAmME
APPLES
P.tArE
0.000 KG
P.tArE
1.000 KG
wW001
SAVE RECORD?
lIb
W001
lIb
PC001
lIb
P001
lIb
C001
lIb
D001
lIb
CC001
4.10 Library
When an item is processed on a regular basis, the item‟s data may be stored in memory for future use.
The following data is stored for each mode.
Mode Record ID Name Preset Tare APW Reference Wt. Under Limit Over Limit Level
Weighing   
Counting    
Percent Weighing    
Check Weighing     
Check Counting      
Dynamic Weighing    
NOTES: LIBRARY must be set to ON in the SETUP menu (Section 3.4.18).
Up to 256 library records may be stored.
4.10.1 Storing Library Data
Select the desired Mode using the Mode button. Press LIBRARY to view the next available memory
location for the active mode.
The display shows the Record ID with a mode prefix and a unique identification number.
Wxxx = Weighing records
PCxxx = Parts Counting records
Pxxx = Percent Weighing records
Cxxx = Check Weighing records
CCxxx = Check Counting records
Dxxx = Dynamic Weighing records
Press No to advance to the next Record ID or press Yes to begin entering the library data for the
displayed Record ID.
The data type appears on the first line. The data value appears on the second line. Use the keypad
to change the data value. Press Yes to accept the data value and move to the next data type.
Weighing Mode Library Records
The Name of the item is displayed. By default, the Name is the same as the Record ID.
Use the keypad to change the value. Press Yes to accept the value.
NOTE: The Name length can be a maximum of 7 characters.
The Preset Tare of the item is displayed. By default, the current Tare is used as the Preset Tare value.
Use the keypad to change the value. Press Yes to accept the value.
To save the record, press Yes.
