Issue 5.8.B IPDirector Version 5.8 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment – July 2010
72
Icon Description
Recording stream
Off-line stream
VTR
XFile
Controlled by ShuttlePRO
Channel locked from this workstation
Channel locked from another workstation
Channel locked for use in a Timeline
Channel is ganged with another channel as part of group 4
Channel is ganged as a Fill channel as part of group 5
Channel is ganged as a Key channel as part of group 5
Channel has been assigned as a PGM
Channel has been assigned as a PRV
Note
hi-res networks appear on top.
If no network is defined in Remote Installer, there will be no XNet root
and the EVS servers will appear as root nodes.
S
TATUS
I
CONS
The primary line for each device in the Channel Explorer shows the machine
status, its name and an icon representing the device type.
EVS video server connected to the XNet with channels
available for use with IPDirector
EVS video server connected to the XNet with available
channels displayed in its sub menu
EVS video server connected to the XNet without an RS-
422 link to a workstation for channel control by IPDirector
XFile connected to the XNet
