Issue 5.8.B IPDirector Version 5.8 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment – July 2010
68
Panel chapter of the part 6 of the user manual for more detailed information:
• Using Action Tags into a Playlist to Trigger Transport Functions or Playout
Effects
• Playlist Macro Command Settings
The Output GPIs Settings window is used to determine how to use the TTL GPIs
and to specify the Advance value.
Advance
In the Advance field, you can specify how many seconds ahead of the timecode
(on which the GPI tag is defined) the Output GPI signal should be sent by the
IPDirector.
2.10.5 I
MAGE
C
APTURE
S
ETTINGS
D
EFAULT
P
ATH FOR
C
APTURED
I
MAGES
This setting allows the operators to specify a path on which the grabbed frames
will be stored:
• If the administrator has specified a path applicable to all users, you will see the
path in this setting but you will not be able to modify it.
• If the administrator has defined a default path for all users, you can modify the
path if requested.
• If the administrator has not defined a default path, you can specify a path for
captures images in this setting. The path needs to point to a shared folder on
the Gigabit Ethernet network and should have the following pattern:
\ \ < M a c h i n e N a m e > \ < S h a r e d F o l d e r > \ .
C
APTURE
I
MAGES ON ALL
G
ANGED
R
ECORDERS OR
L
INKED
C
LIPS
When this option is selected, the image grabbed on a clip will also be grabbed:
• on all the recorder channels ganged to the recorder channel on which the clip is
loaded.
• on all the clips linked to the clip on which the image is grabbed.
