Issue 5.8.B IPDirector Version 5.8 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment – July 2010
106
Button Description
• CLEAR - OUT: works as CLEAR OUT
• CLEAR - ENTER: cancels the applied saved filter in the
Database Explorer.
ENTER The ENTER button can be used alone (see below) or
together with other buttons (refer to the description of the
other buttons)
• In Browse mode, in the Last Created Clips list and in
the Search on TC list, when a clip is loaded on the
controlled channel, pressing the ENTER button
appends it to the default playlist.
• In the SEL XT and the SEL REC lists: pressing the
ENTER button confirms the selection.
• In the Database Explorer tree view: opens or closes a
tree node.
• In the saved filter pane of the Database Explorer:
applies the selected saved filter.
Wheel Mode Buttons
Three buttons are available to select the mode according to which the wheel will
be used. As some of these buttons can be used in association with other buttons,
a totality of 5 wheel modes are available to the users.
Pressing a Mode button activates a wheel mode but does not change the playout
speed.
VAR Mode
The Var wheel mode enables to move in the loaded media at a selected constant
review speed. It is activated by pressing the VAR button. The LED is red.
The zero position is calculated from the current playout speed to correspond to
the point where the speed is null. The following picture represents the positions of
different speed values:
SHIFT VAR Mode
The Shift Var wheel mode is activated by pressing the SHIFT then the VAR
buttons. It is used to fine tune a speed by applying +1% or -1% to the speed. The
