Column Name Description
Storage Name of the storage on which the clip element is stored:
• EVS video server for XT clips
• for nearline defined in the configuration menu: nearline directory for
files
• for detected IP drives: "drive name" on "machine name".
Storage of off-line clip elements are included if Show offline files is
enabled.
Master This information is only for files. The column is empty for clips.
The master file is the first file created for a clip element and detected
on the nearline. The Master column indicates YES.
When shorter clips, are created from a file, they receive the flag NO in
the Master column.
Full Path Only for files.
File Name Only for files.
Cam Pref. Displays a preference value that is generated when clips are created
from an LSM control panel.
Nb Audio
Tracks How many audio tracks the clip has.
Video Format Shows the video format of the clip:
PAL SD 625i, PAL HD 1080i, NTSC HD 1080i, …
Video Codec Shows the video codec of the clip:
DNxHD, MPEG2 i-frame, …
Video Bitrate Shows the video bitrate of the clip: from 20 to 360.
Aspect Ratio 4:3 Letter Box, 4:3 Box, or 16:9.
VBI This has a value when the clip contains information within the picture
such as teletext, VITC or other such data needed by graphics
applications.
Audio Type Mono, Stereo, Dual Stereo, 8 tracks.
5.5. Clip Element Contextual Menu
The Clip Element contextual menu is displayed when right-clicking a clip element line. It is
the same as the Clip contextual menu obtained from the Clips Elements grid.
See section "Clip Contextual Menu" on page 30 for a detailed description of the different
options available.
