VES-1000 Series Ethernet Switch
9-8 System Maintenance 1
Table 9-D Menu 24.1.3 - VLAN Status
FIELD DESCRIPTION
Number of VLANs This is the total number of VLANs on the switch.
Management VID Management VLAN ID is the VLAN ID of the CPU and is used for management only. The
default is "1". All ports, by default, are fixed members (see Menu 17.1.1 - 802.1Q VLAN Static
Entry Setup) of this "management VLAN" so as to manage the device from any port.
VID This is the VLAN identification number configured in menu 17.1.1)
Egress Port These are the VLAN member ports. “E” denotes an egress port. The “|” symbol separates
every five ports.
Untagged Port These are the ports that transmit untagged (“U”) egress frames (in this VLAN).
Elapsed Time This field displays the elapsed time since this VLAN was created.
Status This field displays whether the VLAN is created dynamically using GVRP or static.
9.3 System Information and Console Port Speed
This section describes your system and allows you to choose different console port speeds. To get to Menu 24.2 —
System Information and Console Port Speed:
Step 1. Enter 24 to go to Menu 24 – System Maintenance.
Step 2. Enter 2 to open Menu 24.2 – System Information and Console Port Speed.
Step 10. From this menu you have two choices as shown in the next figure:
Figure 9-7 Menu 24.2 – System Information and Console Port Speed
9.3.1 System Information
System Information gives you information about your system as shown next. These fields are read-only.
Menu 24.2 — System Information and Console Port Speed
1. System Information
2. Console Port Speed
Please enter selection:
