VES-1000 Series Ethernet Switch
11-4 System Maintenance 2
Figure 11-4 Menu 24.11.1 - Secured Client Sets
Table 11-C Menu 24.11.1 - Secured Client Sets
FIELD DESCRIPTION EXAMPLE
# This is the client set index number. 1
A “A” indicates the client set is Active and “N” indicates that it is Not active A
Addr_START The default value for a start and end address is 0.0.0.0, which means you don’t
care which host is trying to use a service (Telnet, FTP, ICMP).
0.0.0.0
Addr_END This field displays the end IP address in a range of client IP addresses that may
use the service(s) defined in the next field. 0.0.0.0
TFI “Y” (Yes) means that the specified service (T for Telnet, F for FTP and I for
ICMP) is enabled for this client set. Similarly, “N” (No) means it is not. YNY
To edit a client set, type a client set index number and then press [ENTER] or press [ESC] to cancel and go back to
menu 24.11.
11.3.2 Secured Client Configuration
Type a client set index number in menu 24.11.1 and then press [ENTER] to display this menu.
Figure 11-5 Menu 24.11.1.1 - Secured Client Configuration
Table 11-D Menu 24.11.1.1 - Secured Client Configuration
FIELD DESCRIPTION EXAMPLE
Active Press [SPACE BAR] once to select Yes and then press [ENTER] to make this
client set active. This displays as “A” in menu 24.1.1. Yes
Menu 24.11.1 — Secured Client Sets
# A Addr_START Addr_END T F I
— - --------------- --------------- — - -
1 A 0.0.0.0 0.0.0.0 Y Y Y
2 N
3 N
4 N
Enter client set (1-4) to configure:
Menu 24.11.1.1 — Secured Client Configuration
Active= Yes
Secured IP:
addr start= 0.0.0.0
addr end= N/A
Service Type:
TELNET Service= Yes
FTP Service= Yes
ICMP Service= Yes
