ZyXEL Communications VES-1000 - Manual (Page 146)

VES-1000 Series Ethernet Switch
B
VES-1012 Specifications
Physical Interfaces
• 19” 1U rack-mountable, wall-mountable unit (VES-1012 Only)
• Two Telco-50 connectors, including
o 1 Telco-50: 12 USER lines (to the VDSL subscriber)
o 1 Telco-50: 12 CO lines (to the central office or PBX)
• One DB-9F RS-232 local console port
• Two RJ-45 auto-negotiating 10/100M Fast Ethernet ports for uplink connection
• Built-in fans
• Temperature and voltage sensors for monitoring
• Surge protection to prevent lightening damage
Dimensions
• 440mm (W) x 290mm (L) x 43mm (H)
Weight
• 4.4 kg
Power Consumption
• 35 watts maximum
• 100-240VAC/1A, 50/60Hz
Fuse Rated
• T3A250VAC
Operating Environment
• Temperature: 0 — 50°C; Humidity: 5% — 95%
Storage Environment
• Temperature: -25 — 70°C; Humidity: 20% — 95%
