VES-1000 Series Ethernet Switch
12-12 VDSL-Related Commands
Figure 12-12 Enet Monitor Statistics
Table 12-H Enet Monitor Statistics
LABEL DESCRIPTION
LT This is the VES-1000 Series switch.
NT This is the subscriber’s VDSL modem (P841).
TxF and RxF Transmitting and Receiving Frame count.
TxB and RxB Transmitting and Receiving Byte count.
TxS and RxS Transmitting and Receiving Throughput in Bytes per second.
12.3.6 VDSL Enet Phy Command
vdsl enet phy chan-id
This command shows Ethernet PHY registers information in hexadecimal format.
Figure 12-13 Ethernet Physical Registers
>vdsl enet mon 2 on
ves-100>108:Enet(LT):Tx(F:0 B:0 S:0) Rx(F:681 B:85833 S:1950)
109:Enet(NT):Tx(F:694 B:90140 S:2709) Rx(F:0 B:0 S:0)
113:Enet(LT):Tx(F:0 B:0 S:0) Rx(F:815 B:117449 S:6323)
114:Enet(NT):Tx(F:828 B:119529 S:5877) Rx(F:0 B:0 S:0)
118:Enet(LT):Tx(F:0 B:0 S:0) Rx(F:876 B:125667 S:1643)
119:Enet(NT):Tx(F:884 B:126557 S:1405) Rx(F:0 B:0 S:0)
123:Enet(LT):Tx(F:0 B:0 S:0) Rx(F:934 B:134174 S:1701)
124:Enet(NT):Tx(F:943 B:134941 S:1676) Rx(F:0 B:0 S:0)
128:Enet(LT):Tx(F:0 B:0 S:0) Rx(F:980 B:138422 S:849)
ves-100>vdsl enet mon off
129:Enet(NT):Tx(F:989 B:139256 S:863) Rx(F:0 B:0 S:0)
ves-100>vdsl enet phy 1
LT Ethernet PHY Registers:
(00) 0x3100 (01) 0x7809 (02) 0x0016 (03) 0xf880 (04) 0x05e1 (05) 0x0000
(06) 0xffff (07) 0xffff (08) 0xffff (09) 0xffff (10) 0xffff (11) 0xffff
(12) 0xffff (13) 0xffff (14) 0xffff (15) 0xffff (16) 0x0022 (17) 0xff40
(18) 0x40a0 (19) 0xffc0 (20) 0x00a0 (21) 0xffff (22) 0xffff (23) 0xffff
(24) 0xffff (25) 0xffff (26) 0xffff (27) 0xffff (28) 0xffff (29) 0xffff
ves-100>
