VES-1000 Series Ethernet Switch
7-2 VLAN Setup
Figure 7-2 Menu 17 VLAN Setup
Table 7-A Menu 17 - VLAN Setup
FIELD DESCRIPTION EXAMPLE
GVRP GVRP (GARP VLAN Registration Protocol) is a registration protocol that
defines a way for switches to register necessary VLAN members on ports
across the network. Enable this function to permit VLANs groups beyond the
local switch. Press [SPACE BAR] once to select Enable and then [ENTER]
to permit GVRP on this port. Enable
Management VLAN
ID Management VLAN ID is the VLAN ID of the CPU and is used for
management only. The default is "1". All ports, by default, are fixed members
(see Menu 17.1.1 - 802.1Q VLAN Static Entry Setup) of this "management
VLAN" in order to manage the device from any port. If a port (VDSL or
Ethernet) is not a member of this VLAN, then users on that port cannot
access the device. To access the device make sure the port that you
connected to is a member of Management VLAN. 1 (default)
Edit 802.1Q VLAN
Static Entry Press [SPACE BAR] once to select Yes and then [ENTER] to open Menu
17.1 - 802.1Q VLAN Static Entry Setup to edit static VLANs. No
Once you have completed filling in Menu 6.1.3 – Port VLAN Setup, press [ENTER] at the message “Press ENTER
to Confirm…“ to save your configuration or press [ESC] at any time to cancel.
7.2.1 Static VLAN Setup
Go to the Edit 802.1Q VLAN Static Entry field in Menu 17 — VLAN Setup and select Yes to open Menu 17.1
— 802.1Q VLAN Static Entry. Menu 17.1 shows all defined static VLANs.
Enter the index of the static entry you wish to configure to open Menu 17.1.1 - 802.1Q VLAN Static Entry
Setup. Menu 17.1.1 allows you configure a static entry.
Figure 7-3 Menu 17.1.1 - 802.1Q VLAN Static Entry Setup
Table 7-B Menu 17.1.1 - VLAN Static Entry Setup
Menu 17 - VLAN Setup
GVRP= Disable
Management VLAN ID= 1
Edit 802.1Q VLAN Static Entry= No
Press ENTER to Confirm or ESC to Cancel:
Menu 17.1.1 - 802.1Q VLAN Static Entry Setup
Name= PVID-1
VLAN ID= 1
Active= Yes
Port01= Fixed-U Port06= Fixed-U Port11= Fixed-U
Port02= Fixed-U Port07= Fixed-U Port12= Fixed-U
Port03= Fixed-U Port08= Fixed-U Port13= Fixed-U
Port04= Fixed-U Port09= Fixed-U Port14= Fixed-U
Port05= Fixed-U Port10= Fixed-U
Trunk1= N/A
Press ENTER to Confirm or ESC to Cancel:
