Figure 11-6 Menu 24.12 - Hardware Monitor
Table 11-E Menu 24.12 - Hardware Monitor
FIELD DESCRIPTION
EXAMPLE
Temperature (C) There are three temperature sensors inside the VES-1000 Series switch.
Each sensor is capable of detecting and reporting if the temperature rises
above the threshold of 65 degrees centigrade. Temp 1 refers to the first
temperature sensor.
Temp1
Current This shows the current temperature in degrees centigrade at this sensor.
35.0
Max This field displays the maximum temperature measured at this sensor.
37.0
Min This field displays the minimum temperature measured at this sensor.
34.0
Threshold This field displays the upper temperature limit at this sensor.
65.0
Status This field displays “Normal” for temperatures below the threshold.
Normal
Fan speed
(VES-1012 only)
A properly functioning fan is an essential component (along with a
sufficiently ventilated, cool operating environment) in order for the VES-1012
switch to stay within temperature thresholds. Each fan has a sensor that is
capable of detecting and reporting if the fan speed falls below the threshold
of 4000 RPM.
Current This field displays this fan’s current speed in Revolutions Per Minute (RPM).
7673
Max This field displays this fan’s maximum speed measured in Revolutions Per
Minute (RPM).
7803
Min This field displays this fan’s minimum speed measured
in Revolutions
Per
Minute (RPM).
7417
Threshold This field displays the minimum speed at which a normal fan should work.
4000
Status “Normal” indicates that this fan is functioning above the minimum speed.
Normal
Voltage (V)
The power supply for each voltage has a sensor that is capable of detecting
and reporting if the voltage falls out of the tolerance range.
V2.0
Menu 24.12 — Hardware Monitor
Temperature(C) Current
Max
Min
Threshold
Status
TEMP1
35.0
37.0
34.0
65.0
Normal
TEMP2
32.5
35.5
30.0
65.0
Normal
TEMP3
43.0
46.0
40.5
65.0
Normal
Fan speed(RPM) Current
Max
Min
Threshold
Status
FAN1 RPM
7670
7803
7417
4000
Normal
FAN2 RPM
7714
7848
7458
4000
Normal
FAN3 RPM
7258
7584
7180
4000
Normal
FAN4 RPM
7714
7894
7541
4000
Normal
Voltage(V)
Current
Max
Min
Tolerance(%) Status
2.0
2.06
2.11
2.02
5
Normal
2.5
2.61
2.62
2.58
5
Normal
3.3
3.31
3.36
3.30
5
Normal
5.0
5.06
5.15
4.99
5
Normal
15.0
14.53
15.02
14.35
5
Normal
-5.0
-5.15
-5.15
-5.25
5
Normal
Press Command:
COMMANDS:r-Reset status ESC-exit
