VES-1000 Series Ethernet Switch
Port Setup 5-5
5.3.1 Configuring VLAN on a Port
Select Yes in the Edit VLAN Setup field in Menu 6.1 — VDSL Port Setup (or Menu 6.13 — Ethernet Port
Setup) to open Menu 6.1.3 — Port VLAN Setup.
Figure 5-5 Menu 6.1.3 Port VLAN Setup
Table 5-D Menu 6.1.3 - Port VLAN Setup
FIELD DESCRIPTION EXAMPLE
Default VLAN ID Default VLAN ID is the PVID (Port VLAN ID) assigned to untagged frames or
priority frames (frames with null (0) VID) received on this port. The default is
1 (see section4.2.8). 1(default)
VLAN Acceptable
Frame Type Choose All if you want the port to accept both tagged and untagged
incoming packets (to that port). Choose Tagged if you want the port to
accept just tagged incoming packets (to that port). See section 4.2.8 for
more information on tagged and untagged frames. All (default)
GVRP GVRP (GARP VLAN Registration Protocol) is a registration protocol that
defines a way for switches to register VLAN members on ports across the
network. Enable this function to propagate VLANs information beyond the
local switch. Press [SPACE BAR] once to select Enable and then [ENTER]
to permit GVRP on this port. Disable
(default)
Once you have completed filling in Menu 6.1.3 — Port VLAN Setup, press [ENTER] at the message “Press
ENTER to Confirm… “ to save your configuration or press [ESC] at any time to cancel.
Menu 6.1.3 - Port VLAN Setup
Default VLAN ID= 1
VLAN Acceptable Frame Type= All
GVRP= Disable
Press ENTER to Confirm or ESC to Cancel:
