VES-1000 Series Ethernet Switch
Port Setup 5-1
Configure your VDSL and Ethernet ports in SMT menu 6.
5.1 Configured Vs. Actual VDSL Port Speed
Configure the maximum speed of an individual VDSL port in this menu. Due to noise and other factors on the
line, the actual speed may not reach the maximum that you specify. See Table 4-C VDSL Mode, Frequency
Ranges and Speeds for the range of speeds you may configure for each VDSL mode.
Enter 6 from the main menu to bring up Menu 6 – Ports Setup.
Figure 5-1 Menu 6 – Ports Setup for VES-1012 Only
5.2 Port Configuration
Port type (VDSL or Ethernet) is labeled under Type in menu 6. Enter the port index number to configure it.
This menu only shows the number of ports that are available on your particular VES-1000 Series switch. As an
example, the VES-1008 will show eight available ports and the VES-1012 will show twelve available ports.
5.2.1 VDSL Port Configuration
Select a VDSL port and then press [ENTER] to go to the VDSL port setup menu.
Chapter 5
Port Setup
Menu 6 – Ports Setup
Type Active User Name
1. VDSL Yes JoeSoap
2. VDSL Yes David
3. VDSL Yes Troy
4. VDSL No John
5. VDSL No ____________
6. VDSL No ____________
7. VDSL No ____________
8. VDSL No ____________
9. VDSL No ____________
10. VDSL No ____________
11. VDSL No ____________
12. VDSL No ____________
13. Ethernet Yes Uplink1
14. Ethernet Yes Uplink2
Enter selection Number :
