VES-1000 Series Ethernet Switch
Switch-Related Commands 13-7
Figure 13-7 Set All Ports As Egress Ports for a Single Port
Set All Ports to be Egress Ports for All Ports
sw vlan set all
Use this command to set all ports (in this example, 0 to 14) to be the egress ports for all ports (0 to 14). This is
effect disables VLAN and has security ramifications for VDSL subscribers.
Figure 13-8 Set All VLAN Ports
13.4.3 VLAN Clear Command
Clear One Port of Specific Egress Ports
sw vlan clear n x1 x2
VLAN map:
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Port 0: O X X X X X X X X X X X X X X
Port 1: X O X X X X X X X X X X X X X
Port 2: X X O X X X X X X X X X X X X
Port 3: X X X O X X X X X X X X X X X
Port 4: X X X X O X X X X X X X X X X
Port 5: X X X X X O X X X X X X X X X
Port 6: X X X X X X O X X X X X X X X
Port 7: X X X X X X X O X X X X X X X
Port 8: X X X X X X X X O X X X X X X
Port 9: X X X X X X X X X O X X X X X
Port10: X X X X X X X X X X O X X X X
Port11: X X X X X X X X X X X O X X X
Port12: X X X X X X X X X X X X O X X
Port13: X X X X X X X X X X X X X O X
Port14: X X X X X X X X X X X X X X O
Where 'O' means the port itself, 'X' means its VLAN member, and '-' is not VLAN
member.
VLAN map:
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Port 0: O — — — — — — — — — — — — X X
Port 1: X O X X X X X X X X X X X X X
Port 2: — — O — — — — — — — — — — X X
Port 3: — X — O — — — — — — — — — X X
Port 4: — X — — O — — — — — — — — X X
Port 5: — — — — — O — — — — — — — X X
Port 6: — — — — — — O — — — — — — X X
Port 7: — — — — — — — O — — — — — X X
Port 8: — — — — — — — — O — — — — X X
Port 9: — — — — — — — — — O — — — X X
Port10: — — — — — — — — — — O — — X X
Port11: — — — — — — — — — — — O — X X
Port12: — — — — — — — — — — — — O X X
Port13: X X X X X X X X X X X X X O X
Port14: X X X X X X X X X X X X X O X
Where 'O' means the port itself, 'X' means its VLAN member, and '-' is not VLAN
member.
