VES-1000 Series Ethernet Switch
Static Route Setup 6-1
Static routes tell the VES-1000 Series switch how to forward management traffic.
6.1 Creating a Static Route
Enter 12 from the main menu to go to Menu 12 – Static Route Setup.
Figure 6-1 Menu 12 – Static Route Setup
Choosing a static route to edit displays the following screen.
Figure 6-2 Menu 12.1 - Edit IP Static Route
The following table describes the fields for Menu 12.1 - Edit IP Static Route Setup.
Table 6-A Edit IP Static Route Menu Fields
FIELD DESCRIPTION EXAMPLE
Route # This is the index number of the route as listed in Menu 12 — IP Static
Route Setup.
Route Name Enter a descriptive name for this route. This is for identification purpose
only.
Active This field allows you to activate/deactivate this static route. Yes
Destination IP
Address This parameter specifies the IP network address of the final destination.
Routing is always based on network number. If you need to specify a
t t i l h t b t k f 255 255 255 255 i th
Chapter 6
Static Route Setup
Menu 12 – Static Route Setup
1. ___________
2. ___________
3. ___________
4. ___________
5. ___________
6. ___________
7. ___________
8. ___________
Enter selection number:
Menu 12.1 — Edit IP Static Route
Route #: 1
Route Name= ?
Active= No
Destination IP Address= ?
IP Subnet Mask= ?
Gateway IP Address= ?
Metric= 2
Press ENTER to Confirm or ESC to Cancel:
