VES-1000 Series Ethernet Switch
VLAN Setup 7-3
FIELD DESCRIPTION
Name Enter a descriptive name (up to 12 characters) for the static VLAN for identification
purposes; for example, “marketing” (without the quotes).
VLAN ID Enter the VLAN ID for this static entry; the valid range is between 1 and 4094.
Active Press [SPACE BAR] once to select Yes and then [ENTER] to activate this static entry.
Port01 ~ Port14 Press [SPACE BAR] to choose from Fixed-U, Fixed-T, Forbidden, Normal-U or Normal-T.
The abbreviations are defined as follows.
Fixed-U
Fixed Registration + Untagged
Fixed-T
Fixed Registration + Tagged
Forbidden
Forbidden Registration
Normal-U
Normal Registration + Untagged
Normal-T
Normal Registration + Tagged
Trunk1 Press [SPACE BAR] to choose from Fixed-U, Fixed-T, Forbidden, Normal-U or Normal-T.
Once you have completed filling in Menu 17.1.1 — 802.1Q VLAN Static Entry Setup, press [ENTER] at the
message “Press ENTER to Confirm… “ to save your configuration or press [ESC] at any time to cancel.
Tagged and Untagged governs the outgoing frames. Fixed/forbidden/normal governs VLAN registration.
Note that care must be taken when configuring VLAN for the management port; if the configuration is not correct,
it will render the VES-1000 Series Switch unreachable from the remote management station. The following are
guidelines for tagged VLAN configuration:
• Reserve one VID specifically for management purpose. Assign that VID to be the management VLAND ID.
• Make sure the member set of the management VID includes the uplink port through which the management
station talks to the VES. If you don’t know which uplink port it is, include both uplink ports in the member
set of the management VID. It generally does no harm in doing this, since typically both uplink ports talk to
each other already.
