P-661H/HW Series User’s Guide
64 Chapter 3 Wizards
The following table describes the fields in this screen.
This screen appears if your Internet connection uses RFC1483 encapsulation in routing mode.
Figure 24 Internet Setup Wizard: ISP Parameters (RFC1483 + Routing Mode)
The following table describes the fields in this screen.
This screen appears if your Internet connection uses PPPoA encapsulation.
Table 13 Internet Setup Wizard: ISP Parameters (PPPoE)
LABEL DESCRIPTION
User Name Enter the user name exactly as your ISP assigned. If assigned a name in the form
user@domain where domain identifies a service name, then enter both components
exactly as given.
Password Enter the password associated with the user name above.
Service Name Type the name of your PPPoE service here. Leave this field blank if your ISP did not
provide you a PPPoE service.
Back Click Back to go back to the previous screen.
Apply Click Apply to finish manual configuration. The ZyXEL Device tries to detect the
connection again. See Section 3.1 on page 60 .
Exit Click Exit to close the wizard screen without saving your changes.
Table 14 Internet Setup Wizard: ISP Parameters (RFC1483 + Routing Mode)
LABEL DESCRIPTION
IP Address Enter the static IP address provided by your ISP.
Back Click Back to go back to the previous screen.
Apply Click Apply to finish manual configuration. The ZyXEL Device tries to detect the
connection again. See Section 3.1 on page 60 .
Exit Click Exit to close the wizard screen without saving your changes.
