P-661H/HW Series User’s Guide
Chapter 1 Getting To Know Your ZyXEL Device 41
The following table describes the LEDs.
1.5 Hardware Connection
Refer to the Quick Start Guide for information on hardware connection.
1.6 Splitters and Microfilters
This section describes how to connect ADSL splitters and microfilters. See your Quick Start
Guide for details on other hardware connections.
Table 2 Front Panel LEDs
LED COLOR STATUS DESCRIPTION
POWER Green On The ZyXEL Device is receiving power and functioning
properly.
Blinking The ZyXEL Device is rebooting or performing diagnostics.
Red On Power to the ZyXEL Device is too low.
Off The system is not ready or has malfunctioned.
ETHERNET Green On The ZyXEL Device has a successful 10Mb Ethernet
connection.
Blinking The ZyXEL Device is sending/receiving data.
Amber On The ZyXEL Device has a successful 100Mb Ethernet
connection.
Blinking The ZyXEL Device is sending/receiving data.
Off The LAN is not connected.
WLAN
(wireless
devices only)
Green On The ZyXEL Device is ready, but is not sending/receiving data
through the wireless LAN.
Blinking The ZyXEL Device is sending/receiving data through the
wireless LAN.
Off The wireless LAN is not ready or has failed.
DSL Green On The DSL line is up.
Blinking The ZyXEL Device is initializing the DSL line.
Off The DSL line is down.
INTERNET Green On The Internet connection is up.
Blinking The ZyXEL Device is sending/receiving data.
Off The Internet connection is down.
