P-661H/HW Series User’s Guide
Chapter 6 Wireless LAN 129
6.8.1 ToS (Type of Service) and WMM QoS
ToS defines the DS (Differentiated Service) field in the IP packet header. The ToS value of
outgoing packets is between 0 and 255. 0 is the lowest priority.
WMM QoS checks the ToS in the header of transmitted data packets. It gives the application a
priority according to this number. If the ToS is not specified, then transmitted data is treated as
normal or best-effort traffic.
Click Network > Wireless LAN > QoS. The following screen displays.
Figure 68 Wireless LAN: QoS
The following table describes the fields in this screen.
Table 46 Wireless LAN: QoS
LABEL DESCRIPTION
QoS
Enable WMM QoS Select the check box to enable WMM QoS on the ZyXEL Device.
WMM QoS Policy Select Default to have the ZyXEL Device automatically give a service a
priority level according to the ToS value in the IP header of packets it sends.
Select Application Priority from the drop-down list box to display a table of
application names, services, ports and priorities to which you want to apply
WMM QoS.
# This is the number of an individual application entry.
Name This field displays a description given to an application entry.
Service This field displays either FTP, WWW, E-mail or a User Defined service to
which you want to apply WMM QoS.
