P-661H/HW Series User’s Guide
Chapter 15 Bandwidth Management 243
15.8.1 Rule Configuration
Click the Edit icon or select User define in the Service field to configure a bandwidth
management rule. Use bandwidth rules to allocate specific amounts of bandwidth capacity
(bandwidth budgets) to specific applications and/or subnets.
Figure 138 Bandwidth Management Rule Configuration
The following table describes the labels in this screen.
Table 101 Bandwidth Management Rule Configuration
LABEL DESCRIPTION
Rule Configuration
Active Select this check box to have the ZyXEL Device apply this bandwidth
management rule.
Enable a bandwidth management rule to give traffic that matches the rule priority
over traffic that does not match the rule.
Enabling a bandwidth management rule also allows you to control the maximum
amounts of bandwidth that can be used by traffic that matches the rule.
Rule Name Use the auto-generated name or enter a descriptive name of up to 20
alphanumeric characters, including spaces.
BW Budget Specify the maximum bandwidth allowed for the rule in kbps. The
recommendation is a setting between 20 kbps and 20000 kbps for an individual
rule.
Priority Select a priority from the drop down list box. Choose High, Mid or Low.
