P-661H/HW Series User’s Guide
52 Chapter 2 Introducing the Web Configurator
IP Subnet Mask This is the WAN port IP subnet mask.
Default
Gateway
This is the IP address of the default gateway, if applicable.
VPI/VCI This is the Virtual Path Identifier and Virtual Channel Identifier that you entered in
the Wizard or WAN screen.
LAN Information
IP Address This is the LAN port IP address.
IP Subnet Mask This is the LAN port IP subnet mask.
DHCP This is the WAN port DHCP role - Server, Relay or None.
WLAN Information (Wireless devices only)
SSID This is the descriptive name used to identify the ZyXEL Device in the wireless
LAN.
Channel This is the channel number used by the ZyXEL Device now.
Security This displays the status of data encryption on the ZyXEL Device.
Security
(not available if you entered the user password)
Firewall This displays whether or not the ZyXEL Device’s firewall is activated.
Content Filter This displays whether or not the ZyXEL Device’s content filtering is activated.
System Status
System Uptime This is the total time the ZyXEL Device has been on.
Current Date/
Time
This field displays your ZyXEL Device’s present date and time.
System Mode This displays whether the ZyXEL Device is functioning as a router or a bridge.
CPU Usage This number shows how many kilobytes of the heap memory the ZyXEL Device is
using. Heap memory refers to the memory that is not used by ZyNOS (ZyXEL
Network Operating System) and is thus available for running processes like NAT,
VPN and the firewall.
The bar displays what percent of the ZyXEL Device's heap memory is in use. The
bar turns from blue to red when the maximum is being approached.
Memory Usage This number shows the ZyXEL Device's total heap memory (in kilobytes).
The bar displays what percent of the ZyXEL Device's heap memory is in use. The
bar turns from blue to red when the maximum is being approached.
Interface Status
Interface This displays the ZyXEL Device port types.
Status This field displays Down (line is down), Up (line is up or connected) if you're using
Ethernet encapsulation and Down (line is down), Up (line is up or connected), Idle
(line (ppp) idle), Dial (starting to trigger a call) and Drop (dropping a call) if you're
using PPPoE encapsulation.
For the WLAN port, it displays Active when WLAN is enabled or Inactive when
WLAN is disabled.
Table 4 Status Screen
LABEL DESCRIPTION
