ZyXEL Communications P-661H Series - Manual (Page 297)

P-661H/HW Series User’s Guide
Appendix A 297
Appendix A
Product Specifications
See also the Introduction chapter for a general overview of the key features.
Specification Tables
Table 126 Device
Default IP Address 192.168.1.1
Default Subnet Mask 255.255.255.0 (24 bits)
Default Password 1234
DHCP Pool 192.168.1.33 to 192.168.1.64
Dimensions (W x D x H) 180 x 128 x 36 mm
Power Specification 12V AC 1A
Built-in Switch Four auto-negotiating, auto MDI/MDI-X 10/100 Mbps RJ-45 Ethernet ports
Operation Temperature 0º C ~ 40º C
Storage Temperature -20º ~ 60º C
Operation Humidity 20% ~ 85% RH
Storage Humidity 10% ~ 90% RH
Distance between the
centers of the holes on
the device’s back.
108 mm
Screw size for wall-
mounting
M3*10
