GS-3012F User’s Guide
7-12 VLAN
Table 7-6 Port Based VLAN Setup
LABEL DESCRIPTION
Outgoing These are the egress ports; an egress port is an outgoing port, that is, a port through which a
data packet leaves. If you wish to allow two subscriber ports to talk to each other, you must define
the egress port for both ports. CPU refers to the switch management port. By default it forms a
VLAN with all Gigabit ports. If it does not form a VLAN with a particular port then the switch
cannot be managed from that port.
Apply Click Apply to save the changes, including the “wizard settings”.
Cancel Click Cancel to start configuring the screen again.
