GS-3012F User’s Guide
Product Specifications A-3
Chart 3 Physical and Environmental Specifications
Weight Main switch: 6Kg
LED
Main switch: BPS, PWR, SYS, ALM,
Per Port: LNK, ACT
Per GBIC Slot: LNK, ACT
Per Management Port: 10, 100
Dimensions
Main switch:
438(W) x 300(D) x 44.45(H) mm
(17.3(W) x 8.9(D) x 2.6(H) inches), 19-inch rack-mount width, 1 U height
Power Supply (AC Unit) 100 - 240VAC 50/60Hz 1.5A max internal universal power supply
Power Supply (DC Unit) DC input of -48VDC－-60VDC, 1.2A Max.
Power Consumption
AC: 36W maximum
DC: 30W maximum
Fuse Rating
T2A250VAC
Caution: For continued protection against risk of fire, replace only with the same type
and fuse rating.
Operating Temperature 0ºC ~45ºC (32ºF to 113ºF)
Storage Temperature -25ºC ~70ºC
Operational Humidity 10% to 90% (Non-condensing)
Safety
UL 60950-1
CSA 60950-1
EN60950-1
IEC60950 -1
EMC
FCC Part15 (Class A)
CE EMC (Class A)
